Utility Trailer · SKU SA-UT-DS-1500KG
Single Axle Utility Trailer 1500kg GVM) with Dropsides
R 35 000.00
Price in ZAR. Delivery charges, if any, are quoted before payment.
Made to order — manufactured in 3–5 working days after your order is confirmed
Dropside Trailer 1500kg is a sturdy single-axle utility trailer designed for commercial, agricultural, and general heavy-duty hauling with a 1500 kg Gross Vehicle Mass (GVM).
- Dimensions
- 2.4m × 1.5m
- Load capacity
- 1200 kg
- Tare weight
- 450 kg
- Condition
- New (built to order)
- Fulfilment
- Delivery or collection
- Brand
- Access Trailers
Specifications
- General Specifications
- Gross Vehicle Mass (GVM): 1500 kg.
- Typical Loadbed Sizes: Ranges from 2.0m x 1.2m up to 3.0m x 1.7m (or larger custom builds).
- Side Height: Typically 300mm to 500mm dropsides (with some utility options up to 1200mm).
- Finish: Usually durable 2K Duco paint or galvanized steel options for corrosion resistance.
- Chassis and Frame:
- Chassis Construction: Heavy-duty ladder frame built with channel steel (such as 76mm x 38mm x 5mm or 100mm x 50mm open channel).
- A-Frame: Reinforced open-channel A-frame drawbar for towing stability.
- Floor: Reinforced 2.5mm hot-rolled mild steel or checker plate steel floor for anti-slip grip and impact resistance.
- Body and Dropsides
- Dropside Panels: Hinged and removable or drop-down steel panels on the sides and/or rear for easy side-loading with a forklift or manual loading.
- Headboard: Fixed front headboard (often built from square tubing) to protect the tow vehicle.
- Tailgate: Reinforced drop-down tailgate, frequently secured with safety chains.
- Tie-Downs / Lashing Points: Integrated heavy-duty rope hooks or lashing rings around the perimeter to secure cargo
- Axles, Wheels, and Brakes:
- Axle Configuration: Single heavy-duty leaf-spring axle rated for 1000kg to 1600kg capacity.
- Wheels & Tyres: 14-inch commercial wheels, usually including a spare wheel mounted on the A-frame.
- Brakes: Braked system equipped with a braked coupler (typically a 2000kg braked coupler) to comply with safety requirements for 1500kg GVM loads.
- Jockey Wheel: Front-mounted heavy-duty jockey wheel (60mm or 48mm) for easy maneuvering when unhitched.
Order this trailer
Fill in the form below — every box marked with a red star is required. We confirm your order, delivery cost (if applicable) and send an invoice with EFT payment details within one business day.
Order total: R 35 000.00 per trailer. By submitting an order you agree to our terms and returns policy. Payment by EFT on invoice — see payment methods.
